Description
General
– Frequency Range: PMR446 Analogue
– Channels: Non LCD 16 Channels, LCD 255 channels
– Channel Spacing: 12.5 kHz / 25 kHz
– Communication Method: Simplex / semi duplex
– Antenna Impedance: 50 ohm
– Antenna:Whip / stubby
– Battery Type: 2000 mAh Li-Ion battery pack
– Power Supply Voltage: 7.4V DC
– Current Drain (nominal): 40mA
– Duty Cycle (5/5/90): 14.5 hours
– Microphone: Internal condenser microphone
– Operating Temperature: -20° to +55°C
– Size (mm): 59.5(W) x 130(H) x 37(D)
– Weight: 277g with battery and aerial
Transmitter
– Power Output: 500mW
– Modulation: 8K0G3E/16K0G3E
– Oscillator Method: PLL
– Frequency Stability: 2.5PPM
– Maximum Deviation: ±2.5 kHz(Narrow)/ ±5 kHz(Wide)
– Audio Distortion: < 5% (1 kHz 60%)
– Spurious Emission: -68 [dBc]
– Hum & Noise: -40 [dB]
Receiver
– Receiver Type: Double Super Heterodyne type
– Sensitivity: -0.25uV (12dB SINAD)
– Frequency Stability: 2.5PPM
– Spurious Rejection: +70 dB
– Adjacent Channel Selectivity: -60 dB (Narrow) , -70 dB (Wide)
– Distortion: < 5% (1 kHz 60%)
– Hum & Noise: -40 dB
– Audio Output: 1W
